INFORMATION DETAILS
ID: 15508800
|
Year: 2020
|
Make: Wallenstein
|
Model: GX620
|
Type: New
|
| MSRP:
N/A |
Engine Size - cc: N/A |
| Digging Depth:: | 6' 4'' (193 cm) |
| Reach From Swing Post : : | 100'' (254 cm) |
| HP Range (Tractor): : | 18 - 28 |
| HP Range (Skidsteer): : | 20 - 48 Mini Skidsteer |
| Minimum Required Hydraulic Flow: : | 5 - 7 gpm (19 - 27 lpm) |
| Includes Flow Divider: : | No |
| Bucket Rotation: : | 180° |
| Swing Arc: : | 180° |
| SAE* Dipper Boom Digging Force: : | 1250 lbs (567 kg) |
| SAE* Bucket Digging Force: : | 2600 lbs (1179 kg) |
| Operating Pressure: : | 1800 psi (12411 kPa) |
| Boom Lift Capacity: : | 385 lbs (175 kg) |
| Ground Clearance: : | 10.5 |
| Transport Dimensions (LxWxH): : | 68'' x 40'' x 63'' (173 cm x 102 cm x 160 cm) |
| Loading Height: : | 62'' (158 cm) |
| Stabilizer Width (Spread) : : | 74'' (188 cm) |
| Overall Operating Height (Fully Raised): : | 92'' (234 cm) |
| Main Boom Cylinder Diameter : : | 2.5'' (64 mm) |
| Dipper Cylinder Diameter : : | 2.25'' (57 mm) |
| Bucket Cylinder Diameter: : | 2.25'' (57 mm) |
| Swing Cylinder Diameter: : | 2'' (51 mm) |
| Stabilizer Cylinder Diameter: : | 2'' (51 mm) |
| Total Weight : : | 575 lbs (261 kg) |
| Mounting Options: : | Subframe, Mini Skidsteer Universal Plate, PT300 (Cat I) |
