INFORMATION DETAILS
ID: 13556529
|
Year: 2017
|
Make: Yamaha
|
Model: BWS 125
|
Type: New
|
| MSRP:
N/A |
Engine Size - cc: 125 cc |
| Engine: | 4-stroke, air-cooled (fan assist), SOHC, 4-valve, single |
| Compression Ratio: | 10:1 |
| Transmission: | Fully automatic CVT |
| Final Drive: | V-belt / Spur gear |
| Wheelbase: | 1,305mm (51.4'') |
| Ground Clearance: | 125mm (4.9'') |
| Bore and Stroke: | 52.4 x 57.9 mm |
| Ignition / Starting: | TCI / Electric Start |
| Length: | 1,910mm (75.2'') |
| Width: | 765mm (30.1'') |
| Height: | 1,125mm (44.3'') |
| Fuel Capacity: | 6.5 litres (1.4 Imp. gal.) |
SELLER DESCRIPTION
|
CONQUER ROAD
The fun loving BWs 125 underwent a significant update in 2016. Not only did we revise the styling, but we also increased the under seat storage capacity, added a digital meter assembly and a rear disc brake. Not stopping there, no pun intended, the front disc brake diameter was increased and we made the cockpit more roomy too. Powered by a fuel injected 125 cc engine, the sporty BWs 125 makes a great urban or suburban commuter.
|
ENGINE
Peppy, 125cc, air-cooled (with fan assist), SOHC, 4-valve, 4-stroke engine produces solid, predictable power and excellent fuel economy.
|
STORAGE
Ultra-convenient, large 29 litre, locking under seat storage compartment can hold selected full-face helmets or other items such as a laptop computer, rain suit, etc.
|
FUEL ECONOMY
Fuel consumption of approximately 37kpl/105mpg. Your actual consumption may vary.
|
|
2017 KEY FEATURES
|
-
Fuel injected, catalizer equipped 125cc engine
-
Fully automatic CVT transmission
-
245 mm front disc with twin piston caliper
-
220 mm rear disc brake
-
Digital instrument with tachometer
-
Large 29 litre under seat storage compartment
-
Preload adjustable rear shocks
-
Twin headlights
|
|
|
ENGINE
|
-
125cc, air-cooled (with fan assist), SOHC, 4-valve, fuel injected, 4-stroke engine produces peppy, easy to use power with excellent fuel economy.
-
Fuel consumption rating of approximately 37 kilometers per litre or 105 miles per gallon (imp.). Your actual consumption may vary.
-
BWs 125 uses regular 87 octane gasoline.
-
Fast, dependable electric starting.
-
Maintenance-free transistor controlled ignition (TCI).
-
produces a strong spark for fast starts
-
provides precise ignition timing / mapping for optimum engine performance at all rpms
-
Fan-assisted, air-cooling.
-
maintains consistent engine temperatures even in stop & go traffic
-
4- valve cylinder head.
-
utilizes two intake & two exhaust valves
-
excellent breathing efficiency & excellent fuel economy
-
Roller rocker arm valve actuation.
-
specially designed roller rocker arms reduce friction for increased power
-
reduce mechanical engine noise for a quiet, enjoyable ride
-
Intake & exhaust valves feature a special "carbon cutter" valve stem design.
-
automatically removes carbon build up from the valve stems
-
maintains maximum engine efficiency & power, even during extended slow speed use
-
(carbon build up on valve stems can lead to sticky valves & poor performance)
-
Lightweight, aluminum cylinder features ceramic composite plating on the cylinder bore.
-
insures uniform heat dissipation
-
coating enhances the thin film of oil between the cylinder & piston, reducing friction & increasing power
-
Wet sump-type oil delivery system with centrifugal oil filtering system.
-
automatically removes any particles found in the oil
-
Automatic cam chain tensioner.
-
reduces mechanical engine noise & maintenance time
-
Lightweight crankshaft & lightweight "gravity cast" aluminum piston.
-
optimizes engine performance & provides fast throttle response
-
reduces mechanical vibration
-
crankshaft utilizes a carburized connecting rod for excellent durability
-
24 mm, "closed loop" throttle body fuel injection system.
-
excellent fuel economy & good throttle response
-
6 hole injector optimizes fuel atomization for strong, peppy power
-
"closed loop system" uses an oxygen sensor to "sniff" spent exhaust & automatically adjusts the fuel / air ratio for reduced emissions
-
fuel injection benefits include choke-free starting, steady idling during warm up, excellent fuel economy & reduced emissions
-
Easy access, dual stage, foam and paper-type air filter is used. Air box design reduces intake noise.
-
Fully automatic CVT transmission (CVT = constantly variable transmission).
-
"twist-the-throttle-and-go" operation
-
no clutch lever or gear shifting involved... the transmission is fully automatic.
-
Environmentally responsible exhaust system produces a very quiet exhaust note.
-
muffler contains a honeycomb-style catalytic converter to reduce emissions
-
Air induction System (AIS) further reduces exhaust emissions.
-
AIS system injects fresh air into the exhaust to ensure complete fuel combustion
-
also helps to maximize the function of the catalytic converters
|
|
|
CHASSIS
|
-
Rugged "underbone-style" steel frame.
-
makes getting on & off the BW's easy
-
Wheelbase, centre of gravity, weight distribution & tire design, have all been engineered to provide light, agile handling & great manoeuvrability.
-
33 mm trailing axle front fork.
-
78mm (3.1") of wheel travel
-
rubber fork gaiters / boots extend service life of fork seals & protect inner tubes from chips
-
Adjustable, dual shock rear suspension.
-
80 mm (3.2") of wheel travel
-
good ride quality
-
3 steps of spring preload adjustability allows rider to adjust for load or road conditions
-
Rugged, 5-spoke aluminum "mag" wheels with wide, tubeless tires.
-
wide, aggressive, tubeless 120/90-10 tires front & rear
-
tires well suited for rough, "pot holed" urban roadways
-
tires provide lots of grip & help create BW's unmistakably fun look
-
245 mm front disc brake with wave style disc & twin piston caliper.
-
"wave style" rotor adds style & increases cooling (more surface area than a round disc)
-
excellent stopping power
-
200 mm rear disc brake with single piston caliper.
-
Both front & rear brakes are hand-operated like on a bicycle... making riding simple and fun.
-
Spacious, 29 litre, lockable under seat storage.
-
can hold selected full-face helmets
-
or everyday commuter items like rain suit, laptop, briefcase, etc.
-
Roomy, textured, one piece rider & passenger seat.
-
provides excellent comfort & plenty of room
-
passenger grab rails for peace of mind
-
6.5 litre fuel tank with locking gas cap.
-
excellent fuel economy means an extended riding range & fewer fill ups
-
easy access, front fairing mounted, locking gas cap
-
in tank electric fuel pump
-
Multifunction, 3 in 1 main key switch
-
operates ignition, fork lock & under seat storage lock
-
special anti-theft "shutter" blocks ignition key hole access to prevent tampering
-
Comprehensive, compact, sporty meter assembly
-
all digital readouts
-
readouts include; speedo, odometer, tach, trip meter, clock & fuel gauge
-
Dual style, 55 watt H1 main headlight with projector style high beam light.
-
excellent illumination & rider visibility
-
design enhances BW's tough yet sporty styling
-
Full-size floorboards & wide front apron.
-
excellent wind & weather protection
|
|
DETAILS
|
-
Handy front mounted storage pocket for small items like cell phone or wallet.
-
Front mounted folding hook for additional carrying convenience, perfect for bags & handbags
-
Rear fender extension reduces road splash
-
Sporty hand guards help protect hands from the cold
-
Easy-to-use centre stand
-
Passenger footpegs
-
Easy access oil level dip stick
-
Side reflectors enhance visibility
-
Low maintenance, sealed battery (battery should be charged during winter storage)
|
