Item Details
ID: 15536620
Make: Kohler
Type: New
Year: 2020
Model: 150RZGC, 60 Hz, Dual Fuel
Item Description
|
Industrial Gaseous Generators
-
Standby Range (kW/kVA) 106-150/106-188
-
Fuel Type Dual Fuel
-
Frequency 60 Hz
-
Speed 1800 RPM
-
Alternator Type Brushless, Rare-Earth, Permanent-Magnet
-
Engine Manufacturer PSI
-
Emissions Non-Certified
|
|
Standard Features
|
-
KOHLER Co. provides one-source responsibility for the generating systems and accessories
-
The generator set and its components are prototype-tested, factory-built, and production-tested
-
The 60 Hz generator set meets NFPA 110, Level 1, when equipped with the necessary accessories and installed per NFPA standards.
-
A one-year limited warranty covers all systems and components. Two- and five-year extended warranties are also available
-
The generator set accepts rated load in one step
|
|
Other Features
|
-
Kohler designed controllers for guaranteed system integration and remote communication
-
The electronic, isochronous governor incorporates an integrated drive-by-wire throttle body actuator delivering precise frequency regulation
|
|
Alternator Features
|
-
Kohler's unique Fast-Response(TM) permanent magnet excitation system delivers excellent voltage response and short circuit capability
-
NEMA MG1, IEEE, and ANSI standards compliance for temperature rise and motor starting
-
Sustained short-circuit current of up to 300% of the rated current for up to 10 seconds and enables down stream circuit breakers to trip without collapsing the alternator field
-
Self-ventilated and drip-proof construction
-
Vacuum-impregnated windings with fungus-resistant epoxy varnish for dependability and long life
-
Superior voltage waveform from a two-thirds pitch stator and skewed rotor
|
