Item Details

Item Description

Volume: 38 m3.

Controlbox with full colour touch screen. Main functions available using 2 joysticks.

Star-shaped PowerRotor of 7 rows and 20mm thick tines with hard facing.

Scraper frame which leads to uniform cropload.

Both rotor and pickup 2m wide.

RapideFlow hydraulic driven intake roller.

Box construction with enforced side panels and cage construction.

Galvanized and powder painted side panels.

Height adjustable drawbar with swiveling towing eye.

Hydraulic suspended drawbar with 2 hydraulic cylinders and accumulator.

RapidStream top frontpanel, fixed with entrance door.

30cm yellow steel extension hinged to the outside.

Unique suspended, floating pick-up with 2x2 pick-up wheels, steering wheels at front.

Wide angle PTO driveshaft with automatic cut out clutch, 1000 rpm drive.

3 sectional knivebar for max 43 knives (cutting length 4,4cm).

Standard equipped with 43 knives (6mm thicks, double edged).

Steel floor with double scraper floor, hydraulically one side driven.

Scraper floor protected with automatic switch off by back door.

Bumper wit LED roadlights, set of 3 LED working lights, mudguards and mudflaps and reflection striping on back door.

24 ton pendulum tandem following steered, with air brakes on 4 wheels, wheelbase 1.420mm, including parking brake.

Tires BKT710/40x22.5 FL630+.

Stock Number :B25
