Item Details

ID: 39361605
Make: Yamaha
Type: Used

Year: 2018
Model: Kodiak
Milleage: 14200 km

Class: A

Codename: YF70KPSJB

Model Code: Kodiak 700 SE

Titlestatus: CLEAN

Unitcondition: EXCELLENT

Main Properties: Array

Source Dealer Info: Array

Item Description

Conquer Dirt

When you rely on your ATV to get the job done, you can't afford overlooking quality, value and reliability. The Kodiak 700 excels in all three and is the most important tool you've got when the job demands a workhorse. The choice is easy.

TERRAINABILITY

• Independent Double Wishbone front and rear suspension offer superior traction on uneven surfaces.
• Electric Power Steering (EPS) reduces rider fatigue and handlebar "kickback"
• Dual hydraulic front disc brakes provide serious stopping power when you need it most.

POWER

• 708cc engine provides lots of linear torque and power delivery for utility applications like towing or hauling heavy loads
• Fuel injection offers fantastic throttle response and fast cold-weather start-up.
• The industry's most durable CVT comes in the form of the Yamaha Ultramatic Transmission. A proven winner, with confidence inspiring downhill engine braking.

DESIGN

• SE only features include 25" aluminum mag wheels and special edition paint & graphics.
• Kodiak 700 EPS SE gets push button, On-Command to put the rider in control of 2WD, 4WD or 4WD full diff lock modes.
• Body design is as practical as it is stylish with excellent spash protection, plenty of storage and easy access to essential maintenance items.

Features & Benefits

Key differences between Kodiak 700 EPS & Kodiak 700 EPS SE:

Stylish aluminum alloy wheels
Special Edition paint & graphics

ENGINE

708cc, liquid-cooled, DOHC, 4-valve, single produces serious torque & horsepower.
Electric starting.
- includes auto decompression system for fast, easy starts
DOHC 4-valve cylinder head design.
- 2-intake (39 mm) & 2-exhaust (32 mm) valves provide maximum breathing efficiency
- compact combustion chamber for optimum combustion speed & reduced heat & power losses
- shim under bucket valve actuation for extended valve adjustment intervals
Aluminum cylinder body with cast iron liner.
- aluminum design reduces weight
- cylinder can be over bored in the event of an issue (2 sizes of overbore)
Short skirt forged aluminum piston with Defric coating.
- reduced reciprocating mass means fast engine response & less mechanical vibration
- Defric coating reduces friction for improved power output
Gear driven balancer shaft.
- reduces engine vibration for improved rider comfort
44 mm Mikuni throttle body fuel injection system with TPS & ISC.
- TPS (Throttle Position Sensor) is used to more precisely calculate the fuel injection quantity for optimum power, excellent throttle response & reduced emissions
- ISC (Idle Speed Control) helps ensure a steady idle even during warm up
- other fuel injection benefits include; choke-free starting, excellent fuel economy & reduced emissions
Throttle speed limiter.
- easy to adjust, screw type throttle speed limiter
High mounted, high capacity air box with washable foam air filter.
- no tools required to access air filter
- washable foam filter reduces tune-up costs
- high mounted design helps prevent water ingestion
- air box features a "no tools required" drain
Yamaha's industry leading "Ultramatic" CVT (fully automatic) transmission with reverse & downhill engine braking.
- dual range, high - low transmission with reverse. Low range offers more "grunt" for towing or hauling heavy loads or when tackling technical terrain.
- CVT automatically selects the optimum transmission ratio, meaning you are always in the right "gear"
- Ultramatic design offers controllable, confidence inspiring downhill engine braking
- downhill engine braking reduces brake wear & servicing
- Ultramatic design features a special centrifugal clutch which keeps constant tension on the V-belt to reduce belt wear since the belt does not slip as the clutches engage
- high mounted belt cooling ducts help prevent water ingestion
- V-belt housing has a "no tools required" drain plug
- automotive style, gated, 5-postion shifter (high, low, neutral, reverse & park)
Super convenient, servo motor controlled, On Command 4WD drive system.
- On Command drive system features 3 modes: 2wd, 4wd limited slip & 4wd differential lock
- On Command drive system lets you select the best mode for the conditions... not the machine
- 4wd differential lock provides power to all 4 wheels for maximum traction and "bite"
- special over ride switch eliminates the differential lock speed limiter if required
- convenient handlebar mounted push button controller
Straight design front & rear drive shafts.
- straight driveshaft layout eliminates U-joints for reduced friction, reduced noise & reduced vibration
- front & rear CV drive shafts feature heavy duty rubber boots to protect the CV joints for extended service life & durability
High capacity cooling system with electric cooling fan.
- maintains consistent engine temperatures for optimum performance
- rad is positioned high in the frame for protection
Wet sump lubrication system.
- spin on type oil filter for fast, easy oil changes
Maintenance-free transistor controlled ignition (TCI).
- produces a strong spark for fast starts
- provides precise ignition timing / mapping for optimum engine performance at all rpms
Stainless steel exhaust system with catalyzer & cleanable spark arrestor.
- spark arrestor prevents stray sparks from exiting the exhaust
- catalyzer reduces exhaust emissions
- stainless steel design helps prevent rusting (muffler is painted)
Air Injection System (AIS) injects fresh air into exhaust port to fully burn any unburnt fuel, reducing exhaust emissions.

CHASSIS

Rugged round tube, steel frame.
- compact design provides nimble, responsive handling
- low seat height (860 mm / 33.9") reduces centre of gravity & improves rider confidence / security
Electric Power Steering (EPS).
- significantly reduces steering effort resulting in less rider fatigue & improved rider comfort
- speed sensitive system; more assist at slower speeds, less assist at higher speeds for optimum control
- significantly reduces handlebar kickback when a front wheel strikes an obstacle
- fully sealed system (electrics & gears)
Adjustable independent double wishbone front & rear suspension.
- 5-position pre-load adjustable, nitrogen charged KYB front & rear shocks
- 193 mm (7.6") front wheel travel & 232 mm (9.1") rear wheel travel
- excellent rider comfort even on the toughest trails
Steel "Wide Arc" style front A-arms.
- "Wide Arc" design increases ground clearance in the centre of the machine
- 275 mm (10.8") of ground clearance
- heavy duty plastic A-arm & CV boot guards
Steel double wishbone rear A-arms.
- utilizes anti-sway bar on rear for optimum handling & reduced body roll
- heavy duty plastic A-arm & CV boot guards
Front hydraulic disc brakes.
- independent (separate) front & rear braking for enhanced control & terrain-ability
- dual 220 mm (8.7") front rotors squeezed by single piston calipers
- pads feature wear indicator grooves for visual pad wear inspection
Rear "wet brake."
- single rear "wet brake" is fully enclosed in the rear gear case housing
- enclosed design keeps mud & water from entering the system & causing premature wear
- consistent braking performance
Lightweight aluminum alloy wheels fitted with high performance MAXXIS tires.
- stylish aluminum alloy wheels
- 25-inch tires
- tire design enhances steering precision, ride comfort & traction
18 litre fuel tank.
- located under the seat to lower the centre of gravity & centralize mass for nimble handling
- reserve portion is 4 litres (low fuel indicator will begin flashing)
Rugged & roomy floorboards.
- excellent rider foot protection
- helps reduce mud & water splash
Fully digital LCD meter assembly.
- functions include: speedometer, odometer, dual trip meters, fuel gauge, hour meter, clock, drive mode indicator, transmission gear indicator & various warning lights
Centrally located storage compartment.
- roomy centre storage compartment (directly in front of the rider) with no tools required drain plug
Convenient, 12 volt DC outlet.
- front fender mounted 10 amp / 120 watt, 12 volt DC outlet for work light, GPS, cell phone, etc...
Full length skid plates.
- underside of unit is fully protected by rugged composite skid plates (3 piece)
- engine oil drain hole in centre skid plate
- skid plates enhance terrain ability by allowing unit to slide more easily over obstacles
High visibility lighting.
- 30/30 watt Krypton main headlights
- handlebar mounted halogen 3^rdheadlight... turns with handlebars
- conventional bulb rear tail light (brake & running lights)
Heavy duty steel front & rear racks & trailer hitch
- front rack max load: 50 kg (110 lbs.)
- rear rack max load: 90 kg (198 lbs.)
- centre-mounted, heavy duty, 2" trailer hitch receiver
- towing capacity: 600 kg (1,322 lbs.)
Aggressive SE styling.
- aggressive, yet stylish painted bodywork with special SE paint & graphics
- injection-molded fenders with special scuff guard finish in selected areas
Low maintenance, sealed battery (battery should be charged during extended storage)

Stock Number :UATV-351
